TVLogic R-7D, 2 x 7” LCD 2RU 1920 x 1080 Dual LCD UHD-4K Ready Rack Mount, 500cd/㎡ (12G/6G/3G/HD/SD-SDI, HDMI)
.png "TVLogic R-7D, 2 x 7” LCD 2RU 1920 x 1080 Dual LCD UHD-4K Ready Rack Mount, 500cd/㎡ (12G/6G/3G/HD/SD-SDI, HDMI)")
.png "TVLogic R-7D, 2 x 7” LCD 2RU 1920 x 1080 Dual LCD UHD-4K Ready Rack Mount, 500cd/㎡ (12G/6G/3G/HD/SD-SDI, HDMI)")
NEU
TOP
-18%
TVLogic R-7D
2 x 7” LCD 2RU 1920 x 1080 Dual LCD UHD-4K Ready Rack Mount, 500cd/㎡ (12G/6G/3G/HD/SD-SDI, HDMI)
2 x 7” LCD 2RU 1920 x 1080 Dual LCD UHD-4K Ready Rack Mount, 500cd/㎡ (12G/6G/3G/HD/SD-SDI, HDMI)
Product Highlights
• 2 × 7” Full HD LCD Screen
• 12G/6G/3G-SDI Input & Output
• HDR Emulation (PQ, HLG, S-Log3)
• Custom 3D LUT Import by USB Flash Drive
• Various Built-in Camera LUTs
• Waveform / Vectorscope
• 16ch Audio Level Meter
• Marker
• Dynamic UMD
• Timecode Display
• Luma(Y’) Zone Check
• Focus Assist
• 1:1 Scan / Zoom
• Blue/Mono Only
• Luma(Y") Zone Check
• H/V Delay
• Tally
TVL-brochure-25-web.pdf
TVL-brochure-25-web.pdf
Shipping specifications
| Brand | TVLogic |
|---|---|
| Itemcode | 2605.0323 |
| Bruto weight | 3 |
| Net weight | 2.5 |
| HS code | 8528529100 - Monitors |
| Shipping dimensions | 50cm x 15cm x 10cm |
| Supplier item code | TVL-R-7D |
Main Body Dimensions
Main Body 430 x 132 x 50.5 (mm) / 16.93 x 4.72 x 1.99 (inch)
With Rack Mount Kit 480.8 x 132 x 73 (mm) / 18.92 x 5.19 x 2.87 (inch)
Weight 2.46Kg / 5.42Ibs
Für weitere Informationen besuchen Sie bitte die Homepage zu diesem Artikel.
