CREW Tx+2Rx 4000feet(1200m) 3rd Gen. professional Wireless with dual NP-F-Mounts
NEU
TOP
-23%
CREW Tx+2Rx
Professional RF, NOT WIFI
The new generation CREW wireless system, upgraded with twice longer transmission distance, enhanced reliable image quality, and uncompromised multicast capabilities. The CREW system continues to deliver the same rock-solid transmission stability as FLOW series, for professional broadcast and film productions.
› KUWI 2.0 Pro wireless tech, NOT WIFI
› Proprietary anti-interference RF
› 5.1-5.9GHz License-Free DFS Comply
› Auto scan and select optimal channel
› 3GSDI & HDMI® HD video transmission
› 1.2km / 4000ft (Line-of-Sight) distance
› USB-C Video Capture out for PC/Mac
› H.265 up to 26.8Mbps visual lossless
› Consistent 32ms ultra low latenty
› Uncompromised 1T to 4R Multicast
› MetaData & TC trigger transmission
› High bright OLED display & configuration
› AES-256 dual encryption protection
› Dual Sided V-mount power and install
› NP-F Mount 2-pin LEMO / USB-C Power Supply
2x Crew-NP-F Rx
6x Backup High Gain Antenna
6x Tags white
6x Tags yellow
3x D-Tap to 2-pin Lemo cable
3x USC-C to C cable
1x USB-A to C OTG
1x Carrying Case
Professional RF, NOT WIFI
The new generation CREW wireless system, upgraded with twice longer transmission distance, enhanced reliable image quality, and uncompromised multicast capabilities. The CREW system continues to deliver the same rock-solid transmission stability as FLOW series, for professional broadcast and film productions.
› KUWI 2.0 Pro wireless tech, NOT WIFI
› Proprietary anti-interference RF
› 5.1-5.9GHz License-Free DFS Comply
› Auto scan and select optimal channel
› 3GSDI & HDMI® HD video transmission
› 1.2km / 4000ft (Line-of-Sight) distance
› USB-C Video Capture out for PC/Mac
› H.265 up to 26.8Mbps visual lossless
› Consistent 32ms ultra low latenty
› Uncompromised 1T to 4R Multicast
› MetaData & TC trigger transmission
› High bright OLED display & configuration
› AES-256 dual encryption protection
› Dual Sided V-mount power and install
› NP-F Mount 2-pin LEMO / USB-C Power Supply
Liferumfang:
1x Crew-NP-F Tx2x Crew-NP-F Rx
6x Backup High Gain Antenna
6x Tags white
6x Tags yellow
3x D-Tap to 2-pin Lemo cable
3x USC-C to C cable
1x USB-A to C OTG
1x Carrying Case
Input / Output
| Transmitter | SDI input×1, loop output ×1 |
|
| HDMI® input×1 |
| Receiver | SDI output×2 |
|
| HDMI® output ×1 |
|
| USB-C Video capture output ×1 |
Video Formats
| SDI / HDMI® | 1080p60, 1080p59.94, 1080p50 |
| 1080p23.98, 1080p24; 1080p25, 1080p29.97, 1080p30; | |
| 1080psf23.98, 1080psf24, 1080psf25, 1080psf29.97, 1080psf30 | |
| 1080i60, 1080i59.94, 1080i50; | |
| 720p60, 720p59.94, 720p50 | |
| Compression | H.265 up to 26.8M bit-rate |
| Embedded Audio | 2-ch |
| Metadata | Yes |
| Timecode & Trigger | Yes |
Wireless
| Frequency | 5.1 - 5.9GHz |
| RF Modules | OFDM 16QAM, 64QAM, QPSK, BPSK |
| RF Power | 23dbm |
| Distance | 1.2km / 4000ft (Line of sight) |
| Latency | 32ms |
| Multicast | 1 Tx up to 4 Rx |
| Encryption | AES-256 |
Power
| Battery Plate | Tx & Rx: NP-F type |
| DC Input | Tx & Rx: 2-pin LEMO 7-17V |
| USB-C Input | Tx: 9V/2A; Rx: 5V/2A |
| Power Consumption | Tx: 16W, Rx: 6W |
General
| Environmental | -10°C to 40°C |
| Dimension | Tx & Rx: 130×80×36.7mm |
| Weight | Net: Tx:333g, Rx: 334g; With package 2.7kg |
