TVLogic LVM-180A, 18.5" (500nit) 1920x1080 Wide Viewing LCD Monitor, 2x 3G/HD/SD-SDI inputs
TOP
-16%
TVLogic LVM-180A
18.5" (500nit) Entry-Level Full-Featured 1920x1080 Wide Viewing LCD Monitor 2X 3G/HD/SD-SDI inputs with one loop out, DVI-I and HDMI inputs, Composite In/Out, Waveform/Vector Scope, Closed Caption : 608/708 (SDI), Focus Assist, Range Error/Y Level Check.
The LVM-180A is 18.5” model with a 18.5 inch IPS LCD panel with 1920x1080 native resolution, 500 nit, enhanced contrast ratio and wide viewing angle all unmatched by other LCD monitors.
A completely redesigned video processing unit provides powerful performance and artifact-free image reproduction.
Support for various cinema camera log-to-linear LUTs, easy field upgradability and a full array of image processing features are standard.
18.5" (500nit) Entry-Level Full-Featured 1920x1080 Wide Viewing LCD Monitor 2X 3G/HD/SD-SDI inputs with one loop out, DVI-I and HDMI inputs, Composite In/Out, Waveform/Vector Scope, Closed Caption : 608/708 (SDI), Focus Assist, Range Error/Y Level Check.
The LVM-180A is 18.5” model with a 18.5 inch IPS LCD panel with 1920x1080 native resolution, 500 nit, enhanced contrast ratio and wide viewing angle all unmatched by other LCD monitors.
A completely redesigned video processing unit provides powerful performance and artifact-free image reproduction.
Support for various cinema camera log-to-linear LUTs, easy field upgradability and a full array of image processing features are standard.
Product Highlights
• 18.5” Full HD Resolution (1920 x 1080)
• Waveform / Vectorscope
• 16ch Audio Level Meter
• Focus Assist
• Marker
• Timecode Display
• Dynamic UMD
• Blue/Mono Only
• H/V Delay
• Luma(Y’) Zone Check
• Range Error
• User Aspect
• Various Scan Modes
• Closed Caption (CC-608, CC-708)
• Tally
• Eco Mode
Main Body Dimensions
Main Body 442.5 x 309.2 x 65.3 (mm) / 17.42 x 12.17 x 2.57 (inch)
With Body 483.5 x 332.89 x 137.5 (mm) / 19.03 x 13.1 x 5.41 (inch)
Weight 5.6kg / 12.34lbs
Shipping specifications
| Brand | TVLogic |
|---|---|
| Itemcode | 2605.0321 |
| Bruto weight | 8.5 |
| Net weight | 5.6 |
| HS code | 8528529100 - Monitors |
| Shipping dimensions | 56cm x 46cm x 29cm |
| Supplier item code | TVL-LVM-180A |
.jpg)
