TVLogic LUM-310X (incl. Flight Case), 31" DCI 4K HDR LCD Referenz Monitor, 4096x2160, 2x3G-SDI, HDMI 2.0, 1.000 cd/m²
TOP
-15%
TVLogic LUM-310X (inkl. Flight Case)
Hauptmerkmale
- High Resolution HDR-REFERENZ Monitor 4096x2160 Pixel
- 1.000cd/m²
- Kontrast 1,000,000:1
- 2x12G-SDI, 2x3G-SDI, 1x HDMI 2.0 Eingänge
- Echte 4K Auflösung
- Unterstützung verschiedener Farbräume inkl. DCI
- Kalibrierung mit externer Sonde möglich
- Dual Cell layer Technologie
- True HDR
Display Spec.
Input
Output
Input Signal
SDI Input Signal Formats
Audio
FPGA Functions
Closed Caption
Calibration
Other Functions
Options Stand, Carrying Case
| Size | 31.1" |
| Resolution | 4096 X 2160 (17:9) |
| Pixel Pitch | 0.1704mm |
| Color Depth | 1.07B |
| Viewing Angle | 178°(H) / 178°(V) |
| Luminance | 1,0cd/m2 |
| Contrast Ratio | 1,000,000:1 |
| Display Area | 698(H) x 368(V) mm |
| 4 X BNC | 12G-SDI A/B Channel Input, 3G-SDI C/D Channel Input |
| 1 X HDMI | HDMI Input |
| 4 X BNC | HD SDI A/B/C/D Channel Output |
| 3G SDI | 2.970Gbps |
| 12G SDI | 11.880Gbps |
| HD SDI | 1.485Gbps |
| SD SDI | 270Mb/s |
| HDMI | 480i/480p/576i/576p/720p/1080i/1080p/2160p |
| SMPTE 425M-A/B | 1080p (60/59.94/50/30/29.97/25/24/23.98/30sF/ 29.97sF/25sF/24sF/23.98sF) / 1080i (60/59.94/54) |
| SMPTE 296 | 720p (60/59.94/54) |
| SMPTE 274 | 1080i (60 / 59.94 / 50) 1080p (30/29.97/25/24/24sF/23.98/23.102sF) |
| SMPTE 260 | 47.95/48/50/59.94/60p) |
| Audio In | Embedded Audio/Analog Stereo (Phone Jack) |
| Audio Out | Analog Stereo (Phone Jack), Internal Speaker(Mono) |
| 1:1 Pixel Mapping Modes for SD/HD, 3G-SDI Level A/B, Audio Level Meter Display, Blue Only, Focus Assist, H/V Delay, Key Lock, Luma(Y') Zone Check, Marker, Max Brightness On/Off, Mono, Time Code Display, UMD, User Aspect, Various Scan Modes, Waveform/Vector, SingleMode |
| CC-608 ANC, CC-608 LINE 21, CC-708 |
| TVLogic Color Calibration Utility, 3D LUT & Adjustable Gamma, 3rd Party 3D LUT Import |
| REMOTE | GPI (RJ45) |
| REMOTE | TVLogic’s specification |
| USB | Firmware update by USB memory stick |
| Ethernet | Ethernet Control support |
