Portkeys LH5P ll, 5" Full-HD LED Touchscreen-Videomonitor , 2000 nits, 1920 x 1080
TOP
-22%
Portkeys LH5P ll
Lieferumfang:
is the most affordable 5.5-inch Wide Color Gamut on-camera monitor with a stunning maximum brightness of 2,000nits and wired/wireless camera control capabilities. This HDMI-only monitor features a rugged and durable design entirely made of aluminum with a complete set of professional monitoring tools ready for your next creative adventures.
Key features:
- 5.5-inch, 10-bit (8+2 FRC) panel with a resolution of 1920 x 1080 and a 1000:1 contrast ratio.
- Daylight-viewable with a maximum brightness of 2,000nits.
- 1 x HDMI input, 1 x HDMI output, 1 x 3.5mm audio output.
- Maximum input resolution: 4K DCI at 24p or 4K UHD at 30p.
- Professional monitoring tools: Waveform, Peaking, ARRI False Color.
- 3D LUT monitoring. Monitoring tools can be set before or after the 3D LUT.
- Wireless camera control for most Sony and Blackmagic Design cameras.
- Touchscreen autofocus (wireless) feature is available for select Sony cameras, including the FX3, a7S III, and A7C.
- Wired camera control for Sony, Canon, Panasonic, BMD, and ZCAM E2.
- TILTA Nucleus N/M wireless follow focus wired control.
- Built-in Sony NP-F style battery plate.
- 5-pin 7.4V-24V power input for external power .
- Lightweight and rugged aluminum housing: only 285g/10.05oz
Lieferumfang:
- 1x PT5 II Monitor
- 1x PT5 II Sonnenblende
- 1x HDMI auf HDMI Kabel
- 1x HDMI-auf-Micro-HDMI-Kabel
- 2x Fallfestes Gummigehäuse
- 1x Monitorhalterung
- 1x Sicherheitsbox
Basic Parameters | |
| Screen Size | 5.5″ |
| Dimension | 144*90*30.8mm |
| Viewing Angle | 178°H/178°V |
| Brightness | 2000nit |
| Resolution | 1920*1080 |
| Contrast Ratio | 1000:1 |
| Weight | 285g |
| Color Depth | 10bit(8+2 FRC) |
| Maximum Power | 13W |
| Material | Aluminum alloy + Toughened glass |
| Input Voltage | DC 7-24V |
| Output Voltage | 4pin Aviation Connector OUT 7.4V(NPF) |
| Video Signal Input | 4K HDMI |
| Video Signal Output | 4K HDMI |
| Support Barrery Model | SONY NP-F970/F960/F750/F550 |
| 5pin Aviation Power Input | Available 7-24V power supply or NPF |
| 5pin Aviation Power Output | Can output 5V1A voltage to power other devices |
| Audio Output | 3.5mm Headphone Jack |
| USB-A | Firmware Update / 3D LUT |
| Fan | Yes |
