Epiphan Pearl Nano, portabler Hardware Encoder mit HDMI und SDI Videoeingängen
NEU
TOP
-15%
Epiphan Pearl Nano
ist der intelligenteste und tragbare Edge-Ecoder für Streaming und Aufnahmen, er bietet die ultimative Mischung aus Portabilität und Vielseitigkeit mit einem raffinierten und dennoch robusten Funktionsumfang, der Aufnahme, Kodierung, HDMI-Pass-Through und Aufzeichnung umfasst.
• Front screen for basic configuration/control and confidence monitoring
• Video inputs for HDMI and SDI
• 4K streaming and recording (with feature add-on)
• Audio inputs for line-level XLR, RCA, and USB
• HDMI program out and pass-through for zero-latency content display
• Custom layout builder for a tailored video program
• Intuitive browser-based UI and local console
• SRT, HLS, MPEG-DASH, RTMP, and RTMPS streaming protocol support
• H.265/HEVC video compression
• Cloud-based configuration and control via Epiphan Cloud
• Comprehensive integration with Kaltura, Panopto, and YuJa
• Power over Ethernet Plus (PoE+) and DC power
• Save recordings directly to an SD card (user supplied)
• Expansion bay for user-supplied M.2 SATA SSD
• Automatically transfer recordings to a USB drive or networked server
• 802.1x network access control
• Lightweight Directory Access Protocol (LDAP)
• Secure Sockets Layer (SSL)
• Integration with Crestron AV systems
Produktdatenblatt
ist der intelligenteste und tragbare Edge-Ecoder für Streaming und Aufnahmen, er bietet die ultimative Mischung aus Portabilität und Vielseitigkeit mit einem raffinierten und dennoch robusten Funktionsumfang, der Aufnahme, Kodierung, HDMI-Pass-Through und Aufzeichnung umfasst.
• Front screen for basic configuration/control and confidence monitoring
• Video inputs for HDMI and SDI
• 4K streaming and recording (with feature add-on)
• Audio inputs for line-level XLR, RCA, and USB
• HDMI program out and pass-through for zero-latency content display
• Custom layout builder for a tailored video program
• Intuitive browser-based UI and local console
• SRT, HLS, MPEG-DASH, RTMP, and RTMPS streaming protocol support
• H.265/HEVC video compression
• Cloud-based configuration and control via Epiphan Cloud
• Comprehensive integration with Kaltura, Panopto, and YuJa
• Power over Ethernet Plus (PoE+) and DC power
• Save recordings directly to an SD card (user supplied)
• Expansion bay for user-supplied M.2 SATA SSD
• Automatically transfer recordings to a USB drive or networked server
• 802.1x network access control
• Lightweight Directory Access Protocol (LDAP)
• Secure Sockets Layer (SSL)
• Integration with Crestron AV systems
Produktdatenblatt
Videoeingänge | |
Anschlüsse |
|
Netzwerk-Eingänge | SRT und RTSP |
Audioeingänge | |
Anschlüsse |
|
Audio Gain Control | 0 dB bis +30 dB |
Ausgänge | |
Videoausgänge |
|
Video-Encodierung | |
Codecs |
|
Farbauflösung | 4:2:0 |
Auflösung |
|
Streaming-Protokolle | RTMP/RTMPS, SRT, HLS, MPEG-DASH, RTSP, MPEG-TS, UPnP |
verschlüsselte Programme | 1x 1080p-bei 60 fps (mit bis zu 2 Full HD-Quellen; 4K als kostenpflichtiges Upgrade) |
Audio-Enkodierung | MP3, PCM und AAC (Sampling 16 bis 48 kHz mit Bitrate von bis zu 320 kbps) |
Netzwerk | 1 × 10/100/1000 Ethernet-Anschluss (RJ45) 802.1x Netzwerk-Sicherheit und Zertifikats-Management |
Speicher | |
SD Karte | bis zu 512 GB EXT4 |
interner Speicher | SATA M.2 2280 SSD (M Key Connector) *nicht im Lieferumfang enthalten |
USB | automatisches oder manuelles kopieren über 1 USB 3.0 Port |
Netzwerkspeicher | FTP, SFTP, SCP, RSYNC, CIFS, AWS, oder WebDav Server |
Aufnahmeformate | AVI, MP4, MOV oder MPEG-TS |
Steuerung | Browser-basiertes Admin-Panel, Frontbildschirm und Steuertasten, Fernanmeldung, HTTP- und RS-232-APIs |
Maße | 206 x 149 x 41 mm |
Gewicht | ca. 907 g |
