ATOMOS Ninja Phone, das ultimative iPhone-Zubehör

Video Input Format
1080p 60/59.94/50/30/29.97/25/24/23.98fps; 720p 60/59.94/50fps

Video CODEC
ProRes HQ/ProRes 422/ProRes LT/ProRes Proxy/H.265 Main 10/H.265 8b/H.264 8b

Video Input Port
HDMI-A

Video Output Port
USB 3.1 Gen1

ProRes HQ/ProRes 422/ProRes LT/ProRes Proxy/H.265 Main 10/H.265 8b/H.264 8b
1080p 60/59.94/50/30/29.97/25/24/23.98fps
720p 60/59.94/50fps

Audio
HDMI 2 Channel 48KHz PCM
USB-C Mic Matches Microphone Sample Rate, Locks Audio to Video

Power
USB Power In: USB-C 5V 3A - Ninja Phone charges phone and accessories when attached
Accessory Port: USB-C 5V/1A + USB 3.0 Data
Battery Compatibility: NP-F550/F750/F970 - Ninja Phone charges phone and accessories when attached
Power Consumption: 2.4W (without charging iPhone); 4W （with iPhone 15 Pro; 10W (with iPad Air Gen5)
Operating Environment Temperature: 0℃~40℃

Dimensions
Height 98.2mm
Width 85.4mm
Depth 17.4mm

Weight
Ninja Phone: 94g
iPhone 15 Pro: 187g
iPhone 15 Pro Max: 221g

Chip
AtomIC 5

Mounting Points 1/4"/20 with guide pins

iPhone Video recording w/Ninja Phone
Video formats recorded: HEVC, H.264, and ProRes
1080p HD video recording at 25 fps, 30 fps, or 60 fps
720p HD video recording at 30 fps
Cinematic mode
HDR video recording with Dolby Vision
ProRes video recording up to HDp60 Internal
Log video recording
Academy Color Encoding System
Cinematic video stabilization (4K, 1080p, and 720p)

Connectivity
5G (sub‑6 GHz and mmWave) with 4x4 MIMO8
Gigabit LTE with 4x4 MIMO and LAA8
Wi‑Fi 6E (802.11ax) with 2x2 MIMO9
Bluetooth 5.3
Second-generation Ultra Wideband chip10
Thread networking technology
NFC with reader mode
Express Cards with power reserve

Location
Precision dual-frequency GPS
Digital compass
Wi-Fi
Cellular
iBeacon microlocation

Recording duration (Hour/TB)

Apple ProRes 422 294 0.132 ~7.5

Apple ProRes 422 LT 204 0.092 ~11

H.265 4.5 0.0040 ~250

H.265 30 0.0135 ~74
