Accsoon CineView SE 4K Wireless Video Transmission System m. SDI / HDMI
NEU
TOP
Accsoon CineView SE 4K
combines 4K wireless video transmission with remote camera control via the Accsoon SEE App. Powered by advanced dual-band technology (2.4GHz + 5GHz) and Accsoon’s RTMS 4.0 protocol, it delivers a highly stable, interference-resistant connection, even in demanding RF environments such as live events or multi-device productions.
Hauptmerkmale:
combines 4K wireless video transmission with remote camera control via the Accsoon SEE App. Powered by advanced dual-band technology (2.4GHz + 5GHz) and Accsoon’s RTMS 4.0 protocol, it delivers a highly stable, interference-resistant connection, even in demanding RF environments such as live events or multi-device productions.
Hauptmerkmale:
- Wireless camera control via Wi-Fi (TX)
- Supports selected Sony and Canon cameras (including FX3, FX30, A7 series, R5, R6, R7, R8)
- Up to 400m transmission range
- Ultra-low latency (<50ms)
- Reliable performance in complex signal environments
- Compact, lightweight design
The CineView SE 4K is fully compatible with CineView M7 monitors, Master 4K (Lite) transmitters and receivers, and the CoMo II intercom system, making it ideal for professional workflows from shooting and monitoring to crew communication.
Note: Camera control is supported via Wi-Fi connection to the transmitter only (not via RX USB connection).
CineView-SE-4K-User-Manual_EN.pdfIn the box:
1 x CineView SE 4K Transmitter
1 x CineView SE 4K Receiver
8 x 2.4GHz/5GHz Antenna
2 x Cold Shoe Mount Adapter
1 x User Manual
1 x Allen Key
Shipping specifications
| Brand | Accsoon |
|---|---|
| Itemcode | 2620.0093 |
| Bruto weight | 1.4 |
| Net weight | 0.9 |
| HS code | 8517699000 - Transmitters & Receivers |
| Shipping dimensions | 31cm x 22cm x 17cm |
| Supplier item code | ACC-WIT10 |
| Sender | Empfänger | |
| Protokoll | proprietäres RTMS 4.0 Protokoll (von Accsoon entwickelt) | proprietäres RTMS 4.0 Protokoll (von Accsoon entwickelt) |
| Video-Eingang |
| / |
| Video-Ausgang |
|
|
| Kamerasteuerung | USB-C | |
| SDI Eingangsformate | 1080p: 23.98/24/25/29.97/30/50/59.94/60fps Level A/B | |
| HDMI Eingangsformate | UHD 4K: 23.98/24/25/29.97/30p 1080p: 23.98/24/25/29.97/30/50/59.94/60p | |
| SDI Ausgangsformate | 1080p: 23.98/24/25/29.97/30/50/59.94/60p Level A | |
| HDMI Ausgangsformate | UHD 4K: 23.98/24/25/29.97/30p 1080p: 23.98/24/25/29.97/30/50/59.94/60p | |
| DC-Port | 5,5 x 2,1 mm, Pluspol in der Mitte | |
| DC-Spannung | 7,4 V ~ 16,8 V | |
| Akku | kompatibel mit NP-F550, NP-F750, NP-F970 Akkus | |
| Leistungsaufnahme |
|
|
| Audio |
|
|
| Latenz |
| |
| Übertragungsreichweite | ≥ 400 m (ohne Hindernisse, ohne Interferenzen) | ≥ 400 m (ohne Hindernisse, ohne Interferenzen) |
| Betriebstemperatur | - 10 °C bis 40 °C | - 10 °C bis 40 °C |
| Maße | 13 x 9,5 x 3,2 cm (ohne Antennen) | 13 x 9,5 x 3,2 cm (ohne Antennen) |
| Gewicht | ca. 245 g | ca. 245 g |
| Anmerkungen | [1] Gemessen bei Videoaufnahmen mit 1080p/60 fps und niedriger Bitrate. [2] Gemessen bei Videoaufnahmen mit 1080p/60 fps und niedriger Bitrate unter Einhaltung der FCC-Vorschriften in einer ungehinderten, störungsfreien Umgebung. | |
